HT Sand Drying Machine/ Equipment

Use sand drying machine is used for drying the fresh sand, also raw gypsum Feature: 1. Use cokebreeze or cooled coal gas as fuel, easy to get the fuel. 2. Sand drying equipment has compact structure, stable, efficient, low energy consumption and good drying effect. 3. Burning furnace has two styles: one using gas as fuel, and the other one using cokebreeze. And it has three feed direction: straight, left and right. But the angle between air blower and feed direction should be 90°C. It is convenient for customer’s choice. 4. It is made up of tipping bucket feeder (vibrating feeder, bucket elevator), transmission drum, burning furnace; the unit gathers with vibrating sieve and dust remove Air ventilation system. The Investment is less, effective, and it can bring prominent economical benefit. Spec/ModelHT625HT625DHT628Capacity(m3 /h)56-88Cokebreeze consumption(kg/t)6075-8075-80Sand moisture from outlet(%)<0.5<0.5<0.5Sand temperature from outlet(°C)606060Main motor modelY132S-4Y132S-4Y132S-4Main motor power(kw)5.55.55.5Speed of rotary drum(r/min)6.598Wet dust removerF3719F3719F3725Exhaust fan4-72-11No4.5A 7.5kw4-72-11No4.5A 7.5kw4-72-11No5A 15kwDisc feederY4415Y4415Y4415Screening machineS456S456BS456BWeight (kg)160001800018000
